Siemens 6AV2124-0MC01-0AX0 SIMATIC HMI TP1200 Comfort Touch Panel Original

Name: Siemens 6AV21240MC010AX0 SIMATIC HMI TP1200 Comfort Touch Panel Original
Brand: Siemens
Price: 1 USD

Quality Siemens 6AV2124-0MC01-0AX0 SIMATIC HMI TP1200 Comfort Touch Panel Original for sale

Brand Name : Siemens

Model Number : 6AV2124-0MC01-0AX0

Certification : CE

Place of Origin : China

MOQ : 1

Payment Terms : T/T

Delivery Time : 2-3 days

Product Name : PLC Industrial Control

Part Number : 6AV2124-0MC01-0AX0

Shipment : DHL

Condition : New

Lead Time : 2-3 days

Warranty : 1 year

Keywords : 6AV2124-0MC01-0AX0

Contact Now

Sinamics 6AV2124-0MC01-0AX0 Overview

6AV2124-0MC01-0AX0 is the Siemens SIMATIC HMI TP1200 Comfort industrial touch panel, designed for reliable machine operation and process visualization in automation systems. It features a 12.1-inch high-resolution TFT widescreen with 16 million colors and intuitive touch control.

Figure 1 shows the front panel of 6AV2124-0MC01-0AX0.

Siemens 6AV2124-0MC01-0AX0 SIMATIC HMI TP1200 Comfort Touch Panel Original

Quick Specs.

Table 1 shows the Quick Specs

Item	Value
Part Number	6AV2124-0MC01-0AX0
Product Name	SIMATIC HMI TP1200 Comfort
Display	12.1" TFT, 1280×800, 16M colors
Operation	Touch
Supply	24 VDC
Interface	PROFINET, PROFIBUS DP, MPI, USB
Memory	12 MB user memory
Protection	IP65 front, IP20 back

Detailed Specification

Parameter	Specification
Brand	Siemens
Type	SIMATIC HMI Comfort Panel
Model	TP1200 Comfort
Order Number	6AV2124-0MC01-0AX0
Screen Size	12.1-inch widescreen
Display Type	TFT color display
Resolution	1280 × 800 pixels
Colors	16 million colors
Operation	Capacitive touch
Supply Voltage	19.2–28.8 VDC (typical 24 VDC)
Power Consumption	Max. 20 W
User Memory	12 MB
Operating System	Windows CE 6.0
Communication	PROFINET, PROFIBUS DP, MPI, Ethernet, USB
Configuration	WinCC Comfort
Protection Class	Front IP65, Rear IP20
Operating Temp	0 °C … +50 °C
Dimensions (W×H×D)	Approx. 330 × 241 × 65 mm

Siemens 6AV2124-0MC01-0AX0 SIMATIC HMI TP1200 Comfort Touch Panel Original
